Product Features

  • Broad capacity range.
  • Low headroom design.
  • Painted safety red.
  • Complies with ASME standards.

Product Specifications


Model DLT Specification
Model numbers shown in red are part of our QUICKSHIP program.
Model Number Capacity (lbs) A Max (in.) B (in.) C (in.) D (in.) E (in.) F (in.) G (in.) HR (in.) Weight (lbs)
DLT-1-20 2000 20 29-3/4 29 4 5/8 1 8 7 29
DLT-1 1/4-28 2500 28 40-1/4 39 5 3/4 1-1/4 8 9-1/2 52
DLT-1 1/2-38 3000 38 51-3/4 47-1/2 6 7/8 1-1/2 10 10-3/4 86
