Loadlink plus, LLP 1 – 300 tonnes



Known worldwide as the original electronic force measurement device to feature an integral display, the Loadlink plus has been in production since 1979. Over the years, the line has been expanded and it is now used on a daily basis for load monitoring and heavy lifts. These can range in capacity from 1t to 300t, and are used by a variety of industrial and commercial industries including manufacturing, transportation, agriculture, oil and gas, utilities, aerospace and clean energy.

This latest version of the well-known product has advanced features and benefits, providing solutions for today’s complicated load test and force monitoring needs. The Loadlink plus features full function push button controls for tare, choice of units (lbs, kg, kN and tonnes), peak hold, preset tare, audible set-point alarm and an overload counter.

The advanced microprocessor-based electronics provide the Loadlink plus with high speed read rates, extreme resistance to industrial level noise and unprecedented stability. This high stability gives the Loadlink plus over 5,000 divisions and the highest standard resolution of any digital dynamometer on the market today. Constructed of high-grade aircraft quality aluminium, Straightpoint’s advanced internal design structure allows the product to once again top the charts with an unmatched weight to strength ratio. Straightpoint’s link style dynamometers are on average 30% lighter than their closest competitor with the same safety rating.

Features and benefits:

  • Large 25mm or 1” LCD display
  • High accuracy
  • Selectable units te, lbs, kN & kg
  • High resolution
  • 100Hz Peak hold
  • Push button tare
  • Light weight
  • Preset tare
  • Overload counter
  • 90db Audible set point alarm
  • RS-485 serial output
  • Design validated by F.E.A.
  • 2-year warranty
  • DNV-GL Type Approval
  • Complies with ASME B30.26
Part Number LLP1T LLP2T5 LLP6T5 LLP12T LLP25T LLP35T LLP55T LLP75T LLP100T LLP150T LLP200T LLP250T LLP300T
Capacity  1000kg 2.5te 6.5te 12te 25te 35te 55te 75te 100te 150te 200te 250te 300te
2200lb 5500lb 14300lb 26000lb 55000lb 77000lb 110000lb 165000lb 220000lb 330000lb 440000lb 550000lb 660000lb
Resolution  0.5kg 0.001te 0.001te 0.002te 0.005te 0.005te 0.01te 0.01te 0.05te 0.05te 0.1te 0.1te 0.1te
1lb 2lb 2lb 5lb 10lb 10lb 20lb 20lb 100lb 100lb 200lb 200lb 200lb
Units  te, lbs, kg & kN
lbs, te, kN &kg
Weight  1.5kg 1.5kg 2.4kg 3.7kg 5kg 8.6kg 13kg 16kg 34kg 46kg 82kg 82kg 118kg
3.3lb 3.3lb 5.3lb 8.2lb 11lb 19lb 28.7lb 35.3lb 75lb 101.4lb 180.8lb 180.8lb 260lb
Safety Factor 12.1 7:1 7:1 7:1 5:1 5:1 5:1 5:1 5:1 4:1 5:1  4:1  5:1
Protection IP65
Battery Type 9v PP3
Battery Life 80 hours continuous
Display Type  6 digit 25mm LCD
6 digit 1″ LCD
Operating Temp  -10 to +50 °C
14 to 158˚F
Accuracy ±0.1% full scale
Dimension A  204 204 249 305 340 393 424 470 608 670 700 700 806
8.03 8.03 9.80 12.01 13.39 15.47 16.69 18.50 23.94 26.38 27.56 27.56 31.73
Dimension B  43 43 43 47 60 75 75 75 99 99 144 144 150
1.69 1.69 1.69 1.85 2.36 2.95 2.95 2.95 3.90 3.90 5.67 5.67 5.91
Dimension C  104 104 113 113 115 126 180 202 255 303 350 350 426
4.09 4.09 4.45 4.45 4.53 4.96 7.09 7.95 10.04 11.93 13.78 13.78 16.77
Dimension D  146 146 165 193 215 225 230 260 320 360 350 350 350
5.75 5.75 6.50 7.60 8.46 8.86 9.06 10.24 12.60 14.17 13.78 13.78 13.78
DimensionØ E  24.5 24.5 38 47.5 55 60 76 76 109 109 145 145 160
0.96 0.96 1.50 1.87 2.17 2.36 2.99 2.99 4.29 4.29 5.71 5.71 6.30
Dimension F  48 48 65          Not relevant in this capacity
1.89 1.89 2.60
Dimension G  19 19 32
0.75 0.75 1.26
Crosby Shackle G2130 G2140
Loading Pin Ø  19 19 25 35 51 57 57 70 83 95 121 127 152
3/4″ 3/4″ 1″ 1 3/8″ 2″ 2 1/4″ 2 1/4″ 2 3/4″ 3 1/4″ 3 3/4″ 4 3/4″ 5″ 6″
