Product Features

  • Lightweight.
  • Non-Conductive.
  • Corrosion Resistant.
  • Complies with ASME B30.20, design category B, service class 4.
  • Proof tested with certificate issues.

Dura-Lite™ Composite Lifting & Spreader Beams
Learn about our innovative, patent pending Dura-Lite™ Composite Lifting & Spreader Beams. These lightweight lifters are engineered to withstand the demands of rugged environments while being easy to handle and transport! Contact us today to find out how this innovative solutions can work for you.

Product Specifications

Model 419 Specifications
Model numbers shown in green are part of our INSTOCK program.
Model Number Capacity (tons) Spread (in.) HR (in.) A (in.) B (in.) C (in.) O (in.) Weight (lbs.)
419-1/4-2 1/4 24 13.5 .38 1.50 2.0 .89 8
419-1/4-3 1/4 36 13.5 .38 1.50 2.0 .89 10
419-1/4-4 1/4 48 13.5 .38 1.50 2.0 .89 12
419-1/4-6 1/4 72 16.5 .38 1.50 2.0 .89 25
419-1/4-8 1/4 96 16.5 .38 1.50 2.0 .89 31
419-1/4-10 1/4 120 18.5 .38 1.50 2.0 .89 50
419-1/4-12 1/4 144 16.5 .38 1.50 2.0 .89 65
419-1/4-14 1/4 168 18.5 .38 1.50 2.0 .89 97
419-1/2-2 1/2 24 13.9 .38 1.50 1.94 .89 9
419-1/2-3 1/2 36 13.9 .38 1.50 1.94 .89 10
419-1/2-4 1/2 48 14.9 .38 1.50 1.94 .89 14
419-1/2-6 1/2 72 16.9 .38 1.50 1.94 .89 27
419-1/2-8 1/2 96 18.9 .38 1.50 1.94 .89 44
419-1/2-10 1/2 120 18.9 .38 1.50 1.94 .89 79
419-1-2 1 24 19.6 .63 2.8 4.5 .89 14
419-1-3 1 36 19.6 .63 2.8 4.5 .89 16
419-1-4 1 48 21.6 .63 2.8 4.5 .89 24
419-1-6 1 72 23.6 .63 2.8 4.5 .89 38
419-2-2 2 24 21.9 .63 2.80 4.31 .91 23
419-2-3 2 36 21.9 .63 2.80 4.31 .91 32
419-2-4 2 48 25.9 .63 2.80 4.31 .91 55
419-2-6 2 72 25.9 .63 2.80 4.31 .91 68
419-3-2 3 24 24.9 .63 2.80 4.31 1.0 31
419-3-3 3 36 24.9 .63 2.80 4.31 1.0 34
419-3-4 3 48 26.7 .63 2.80 4.31 1.0 57
