Dura-Lite™ Composite Spreader Beams
Durable composite materials are bonded together to form ultra-strong lifters. These lightweight products are engineered to withstand the demands of rugged environments while being easy to handle and transport! Our patent pending Dura-Lite beams comply with current ASME B30.20, Design Category B, Service Class 4 and are proof tested with a certificate issued.
Product Features
- Lightweight.
- Non-Conductive.
- Corrosion Resistant.
- Complies with ASME B30.20, design category B, service class 4.
- Proof tested with certificate issues.
Dura-Lite™ Composite Lifting & Spreader Beams
Learn about our innovative, patent pending Dura-Lite™ Composite Lifting & Spreader Beams. These lightweight lifters are engineered to withstand the demands of rugged environments while being easy to handle and transport! Contact us today to find out how this innovative solutions can work for you.
Product Specifications
| Model 430 Specifications | ||||||||
|---|---|---|---|---|---|---|---|---|
| Model numbers shown in green are part of our INSTOCK program. | ||||||||
| Model Number | Capacity (tons) | Spread (in.) | HR (in.) | A (in.) | B (in.) | C (in.) | O (in.) | Weight (lbs.) |
| 430-.25-2 | 1/4 | 24 | 23.9 | .63 | 2.80 | 5 | .89 | 7.6 |
| 430-.25-3 | 1/4 | 36 | 29.9 | .63 | 2.80 | 5 | .89 | 9.6 |
| 430-.25-4 | 1/4 | 48 | 35.9 | .63 | 2.80 | 5 | .89 | 11.9 |
| 430-.25-6 | 1/4 | 72 | 47.9 | .63 | 2.80 | 5 | .89 | 16.3 |
| 430-.25-8 | 1/4 | 96 | 59.9 | .63 | 2.80 | 5 | .89 | 20.4 |
| 430-.25-10 | 1/4 | 120 | 71.9 | .63 | 2.80 | 5 | .89 | 24.7 |
| 430-.25-12 | 1/4 | 144 | 85.4 | .63 | 2.80 | 5 | .89 | 45.5 |
| 430-.25-14 | 1/4 | 168 | 98.4 | .63 | 2.80 | 5 | .89 | 67.2 |
| 430-.25-16 | 1/4 | 192 | 110.4 | .63 | 2.80 | 5 | .89 | 76.1 |
| 430-.25-18 | 1/4 | 216 | 122.4 | .63 | 2.80 | 5 | .89 | 86.1 |
| 430-.25-20 | 1/4 | 240 | 134.4 | .63 | 2.80 | 5 | .89 | 135.6 |
| 430-.5-2 | 1/2 | 24 | 23.9 | .63 | 2.80 | 5 | .89 | 7.5 |
| 430-.5-3 | 1/2 | 36 | 30 | .63 | 2.80 | 5 | .89 | 9.6 |
| 430-.5-4 | 1/2 | 48 | 36 | .63 | 2.80 | 5 | .89 | 11.9 |
| 430-.5-6 | 1/2 | 72 | 48 | .63 | 2.80 | 5 | .89 | 16.3 |
| 430-.5-8 | 1/2 | 96 | 61.5 | .63 | 2.80 | 5 | .89 | 32.3 |
| 430-.5-10 | 1/2 | 120 | 74.5 | .63 | 2.80 | 5 | .89 | 49.1 |
| 430-.5-12 | 1/2 | 144 | 86.5 | .63 | 2.80 | 5 | .89 | 59.2 |
| 430-.5-14 | 1/2 | 168 | 98.5 | .63 | 2.80 | 5 | .89 | 96.2 |
| 430-.5-16 | 1/2 | 192 | 110.5 | .63 | 2.80 | 5 | .89 | 110.4 |
| 430-1-2 | 1 | 24 | 23.9 | .63 | 2.8 | 5 | .89 | 12.6 |
| 430-1-3 | 1 | 36 | 30.8 | .63 | 2.8 | 5 | .89 | 15.1 |
| 430-1-4 | 1 | 48 | 36.8 | .63 | 2.8 | 5 | .89 | 17.9 |
| 430-1-6 | 1 | 72 | 50.3 | .63 | 2.8 | 5 | .89 | 31.4 |
| 430-1-8 | 1 | 96 | 63.3 | .63 | 2.8 | 5 | .89 | 51.1 |
| 430-1-10 | 1 | 120 | 75.3 | .63 | 2.8 | 5 | .89 | 82.6 |
| 430-2-2 | 2 | 24 | 26.2 | .63 | 2.80 | 5 | .91 | 20.6 |
| 430-2-3 | 2 | 36 | 32.2 | .63 | 2.80 | 5 | .91 | 22.7 |
| 430-2-4 | 2 | 48 | 39.7 | .63 | 2.80 | 5 | .91 | 31.2 |
| 430-2-6 | 2 | 72 | 52.7 | .63 | 2.80 | 5 | .91 | 46.5 |
| 430-2-8 | 2 | 96 | 64.7 | .63 | 2.80 | 5 | .91 | 72.8 |
| 430-3-2 | 3 | 24 | 27 | .63 | 2.80 | 5 | 1.0 | 22.8 |
| 430-3-3 | 3 | 36 | 33 | .63 | 2.80 | 5 | 1.0 | 25.1 |
| 430-3-4 | 3 | 48 | 41.4 | .63 | 2.80 | 5 | 1.0 | 39.9 |
| 430-3-6 | 3 | 72 | 53.4 | .63 | 2.80 | 5 | 1.0 | 62.5 |
