Product Features

  • Low headroom design for optimum lifting capabilities.
  • One person operation minimizes handling cost.
  • Self-locking worm gear drive for leg adjustment is standard.
  • Easy adjustment for different sheet widths.
  • Rack and pinion leg drive.
  • Designed for ease of maintenance.
  • Designed for greater sheet width range.
  • Complies with ASME standards.

Product Options

  • Hand wheel lockout.
  • Motorized leg adjustment.
  • Chain-wheel leg adjustment.
  • Extended length hand wheel leg adjustment.
  • End chains with plate hooks (recommended for all widths 72” and greater).
  • Extended grab shoe lengths available.
  • Additional bundle clearance available (longer legs).

Product Specifications

Model 60 Specifications
Model numbers shown in red are part of our QUICKSHIP program.
Model Number Capacity (tons) Min. Bundle Width (in.) Max. Bundle Width (in.) HR (in.) D (in.) Min. Aisle (in.) A (in.) B (in.) C (in.) T (in.) Weight (lbs.)
60-3-48 3 16 48 28 2.63 9 1.5 3 5 .75 920
60-3-60 3 16 60 28 2.63 9 1.5 3 5 .75 950
60-3-72 3 16 72 28 2.63 9 1.5 3 5 .75 980
60-5-48 5 16 48 29 2.63 9 2 4 6 1 1125
60-5-60 5 16 60 29 2.63 9 2 4 6 1 1170
60-5-72 5 16 72 29 2.63 9 2 4 6 1 1220
60-5-84 5 16 84 29 2.63 9 2 4 6 1 1270
60-5-96 5 16 96 29 2.63 9 2 4 6 1 1550
60-10-48 10 16 48 30 3.5 11 2 4 7 1.5 1510
60-10-60 10 16 60 30 3.5 11 2 4 7 1.5 1570
60-10-72 10 16 72 30 3.5 11 2 4 7 1.5 1640
60-10-84 10 16 84 30 3.5 11 2 4 7 1.5 1700
60-10-96 10 16 96 30 3.5 11 2 4 7 1.5 1770
60-15-48 15 16 48 32 3.5 12 2.5 5 9 1.5 1570
60-15-60 15 16 60 32 3.5 12 2.5 5 9 1.5 1640
60-15-72 15 16 72 32 3.58 12 2.5 5 9 1.5 1700
60-15-84 15 38 84 32 3.5 12 2.5 5 9 1.5 1960
60-15-96 15 38 96 32 3.5 12 2.5 5 9 1.5 2030
