Product Features

  • Handles narrow coils with less coil edge damage.
  • More durable than web slings.
  • Lightweight for easier handling.
  • Built in guide handle for ease of coil positioning.
  • Available with optional curved coil saddle.
  • Inside radius on hooks avoid coil edge contact.
  • Complies with ASME standards.

Product Specifications


Model 82NC Specifications
Model numbers shown in red are part of our QUICKSHIP program.
Model Number Capacity (tons) Coil Width Max (in.) Throat (in.) L (in.) D (in.) HR (in.) A (in.) B (in.) C (in.) T (in.) Weight (lbs)
82NC-1/2-8 1/2 8 14-1/2 8 2-1/4 18-1/2 13/16 2 3-1/4 1/2 14
82NC-1/2-12 1/2 12 14-1/2 12 2-5/8 18-1/2 13/16 2 3-1/4 1/2 17
82NC-1-8 1 8 17-1/2 8 2 21-1/2 13/16 2 3-1/4 1/2 15
82NC-1-16 1 16 17-/12 16 2-1/2 21-1/2 13/16 2 3-1/4 1/2 20
82NC-2-8 2 8 19-1/2 8 2-1/8 24-9/16 1 2-9/16 4-1/16 3/4 22
82NC-2-16 2 16 19-1/2 16 3 24-9/16 1 2-9/16 4-1/16 3/4 40
82NC-3 1/2-12 3-1/2 12 21-1/2 12 2-7/8 28-1/8 1-3/16 3-5/8 5-5/16 1 50
82NC-3 1/2-16 3-1/2 16 21-1/2 16 3-3/8 28-1/8 1-3/16 3-5/8 5-5/16 1 63
82NC-5-16 5 16 25-1/2 16 3-1/2 32-13/16 1-1/2 4 5-13/16 1-1/4 94
82NC-5-20 5 20 25-1/2 20 4 32-13/16 1-1/2 4 5-13/16 1-1/4 110
